Description
Description
- With EMERGENCY STOP switch in red for immediate power interruption.
- With residual current circuit breaker 30mA (type A), 3x LS 16A for increased safety.
- Robust, impact-resistant plastic housing.
- Protective cover for fuses.
- Ergonomic carrying handle for easy transportation.
- Oil-resistant rubber cable for permanent outdoor use.
RCD personal protection switch
- An RCD (residual current circuit breaker) is an electrical protective device that is primarily used to protect against electric shocks
- The RCD recognises the difference between the incoming and outgoing current in a circuit and automatically switches off the circuit in the event of a residual current
- When used for personal protection, a residual current device must trip and interrupt the circuit at a residual current of 30mA at the latest
Technical data
Technical data
- Cable designation: H07RN-F 3G2,5
- Cable length: 1,70 m
- Cable quality: Rubber-Neoprene
- Max. electr. load capacity: 3680 W
- Nominal input voltage: 230 V
- With carrying handle: Yes
- Housing material: Plastic
- Residual current circuit breaker (RCCB): FI with IFN 0.03 A (standard)
- Number of CEE socket outlets total: 3
- Degree of protection (IP): Plug connection CEE IP67
- Suitable for outdoor area: Yes
- Width of product (without packaging): 18,50 cm
- Weight of product (without packaging): 2,60 kg
- Height of product (without packaging): 12 cm
- Length of product (without packaging): 47 cm
Downloads
Downloads
All products are subject to technical changes
